Fuel Tank Level Sensor Alarm

Overfill Sensor for top loading system can monitoring the level in the fuel loading process, the state of liquid in the tank, an overfill situation, and/or verify the grounding condition.

Features:

1. With interlocking function, if the static ground is not connected reliably, the third party cannot work(can not open the valve, pump, etc.)

2. The performance of the single-chip computer system is stable and reliable.

3. The level switch self- test failure, there is a failure to send and light alarm information, easy operation and use

Specification

Product Features

1. Interlock Function：if the static grounding is not well connected, the third system can't work(Valves can't be lifted and pumps can't be started)

2. Single-chip-computer：He Protector uses single-chip-computer to assure a stable performance of the system.

3. Continuous self-check：The Overfill Sensor for Top Loading System has a continuous self-check and alert feature to insure the system is working properly, thus greatly facilitate the operation.

4. Alarm information provided：The resistance value and audible and visible alarm information can be provided.

5. On-off signals of liquid level：The Protector provides the on-off signals of liquid level and static grounding state for the use of third system

6. Safe Circuits：The relevant equipment of the explosion resistant enclosure, output control circuit,primary instrument and its processing circuit adopt intrinsically safe circuits.

Product Descriptions

The Overfill Sensor for Top Loading System is a device in the process of loading and unloading to ensure safety. It is mainly suitable for inflammable and explosive oil depot and gas station, by monitoring the container liquid level height, when the liquid level rose to a dangerous height, sound and light alarm prompt and output signals, automatically disconnect loading system, in order to prevent oil spill accidents.
